15" Fanless All-in-One PC with RFID and Barcode Scanner

Description

15" LCD Display with 1024*768 Resolution
Intel Celeron J1900 Quad-Core CPU
10-pionts Capactive Touch screen with IP65 Front Bezel
Integrated RFID reader & 1D, 2D scanner
Reliable Thermal Metal Design for 24/7 Use

Model Number: EB-15SR

Make Inquiry Now
OVERVIEW
Specifications
Downloads
Video

Touch Screen Computer built-in  RFID Reader and Barcode Scanner

The #EB-15SR features a 15" capactive touch screen with a 4:3 screen ratio. It runs on an Intel Bay Trail Celeron J1900 quad-core CPU.
This 15 inch touch screen computer built-in RFID reader & 2D scanner, which can be embedded into the enclosure.
including an integrated 2D Barcode Scanner and RFID reader allow this touch screen panel computer to integrate seamlessly into your workflow.
This Aluminum case touch screen computer have HD displays and responsive PCAP touch screen, making it great for the industrial applications.
This touch computer is built with industrial-grade materials and will reliably run on your machine/devices, assembly line, or in your production facility.

RFID Panel PC

RFID Panel PC

Processor Family Intel Celeron Bay Trail
Processor Model J1900 Quad Core , 2.0 GHz, i3, i5 for Options
Memory Type 2*DDR3L SO-DIMM
Memory Support 2GB, 4GB, 8GB
Storage type 2.5" SATA Drive Bay for SSD/HDD
Storage support 32GB-1TB



Display

Screen Size 15"
Resolution 1024 * 768 (XGA)
Screen Ratio 4:3
Brightness 400 nits
Contrast Ratio 600:1
Viewing Angle 160º (H), 160º (V)
Number of Colors Supported 16.7M

Touch Screen

Touch Screen Projected Capacitive Touch Screen



External I/O ports

USB 3*USB 2.0, 1*USB 3.0
Serial Protocol Detail 2* RS-232, 1*RS-232/422/485 (RS485 supports auto flow control)
Ethernet / LAN 1* RJ45 GbE LAN
Audio 1*Audio Line-Out, 1*Microphone Jack
Power Input Port 2-Pole DIN
Wireless connectivity Wi-Fi, 4G, Bluetooth

Power Supply

Input Voltage Range 12 DC  (9~36V wide range voltage optional)
Max Power consumption 29W
Standard Power Adapter AC to DC Output 12V

Operating Systems

Windows Windows 10 or Linux OS

Thermal and Environmental

Operating Temperature 0°C – 50°C
(32°F – 122°F)
Storage Temperature -20°C – 65°C
(-4°F – 149°F)
Humidity Range 10% – 90% Non-condensing
Cooling Solution Passive – Fanless with Heatsink

Enclosure

Material Aluminum, Optional Stainless Steel Bezel, Steel
Ip Rating IP65 Front Bezel
Mounting Options Panel Mount, VESA Mount

Built-in functions

RFID Reader 125Khz, 13.56Mhz RFID reader or writer ( customers required)
Scanner 1D, 2D scanner

Compatibility

Security Hardware Optional TPM

Customized design based on the requirements.
